550°C 耐火ガラス繊維 防火用用用 16オンス

Place of Origin:中国
Brand Name:SUNTEX
Model Number:GF400-WS224-3026
Minimum Order Quantity:20のロール
Payment Terms:T/T;L/C、Paypal…
Supply Ability:500000sqm/month
Product Details
ハイライト:

550°C 耐火ガラス繊維

,

自滅性アクリルコーティングガラス繊維の布

,

16オンス 防火ガラス繊維

Color: 赤
Application: 火の毛布/カーテン
Thickness: 0.017"
Density: 16オンス
Continous Temperature: 550の摂氏温度
Treatment: 扱われる織り方セット
Product Description

16オンス アクリルコーティング耐火性グラスファイバーファブリック防火ブランケット防火カーテン



GF400-WS224-3026は、アクリル処理を施した織物グラスファイバーファブリックです。 最大温度550℃まで対応0火から離れると2秒で自己消火します。



アクリル処理は、空気中の繊維を減らし、耐摩耗性と保存性を高め、有毒な煙のガス放出の可能性を排除します。 処理後 機械的性能も大幅に向上し、縫製、切断、穴あけが容易になります。



これは人間と動物に優しく、完全にアスベストフリーです。



このタイプグラスファイバーファブリック は赤色ですが、Suntexは 色を提供しています OEM も同様です。



550°C 耐火ガラス繊維 防火用用用 16オンス



技術データ:



ベースファブリック ベースファブリックスタイル番号 GF400
  (メートル法) (英語) 試験方法
織り方 平織り 平織り
糸
経糸 EC9 33 1*4 ECG 150 1/4
緯糸 EC9 33 1*4 ECG 150 1/4
構造
経糸 18 ± 1 本/cm 48 ± 3 本/インチ ASTM D 3775-96
緯糸 12.6 ± 1 ピック/cm 32 ± 3 ピック/インチ ASTM D 3775-96
重量 410 ± 20 g/m2 12.6 ± 0.58 oz/yd2 ASTM D3776-96
厚さ 0.37 ± 0.02 mm 0.0145 ± 0.0008 インチ ASTM D1777-96






仕上げファブリック 仕上げスタイル番号 WS224-3026
コーティング アクリル織りセット仕上げ両面、高添加。
重量 550 ± 20 g/m2 16 ± 0.59 oz/yd2 ASTM D3776-96
厚さ 0.42 ± 0.02 mm 0.017 ± 0.0007 インチ ASTM D1777-96
色 赤
耐熱性 5500℃ 10000°F



利点:



1. OEM色。エンドユーザーは好きな色を選択できます。

2. 穴あけ、縫製、加工が容易です。

3. 優れた耐摩耗性。

4. 優れた引張強度。



主な用途:



1. ハルボード。

2. 防火保護ブランケット、溶接ブランケット

3. 航空宇宙熱アブレーションカバー
